Memo:
Ripping and cross-cutting of Panels, Plastic Laminated and Veneered on both sides.
MDF panels, blockboard, soft fiber board, plywood panels, cement bonded plastic
board, solid wood and so on.
Items No | D(mm) | B/b(mm) | Z | d(mm) | Price (usd) |
SHMTP15048 | 150 | 2.6/1.8 | 48 | 30/25 | |
SHMTP16048 | 160 | 2.6/1.8 | 48 | 30/25 | |
SHMTP18056 | 180 | 2.6/1.8 | 56 | 30/25 | |
SHMTP18060 | 180 | 2.6/1.8 | 60 | 30/25 | |
SHMTP19052 | 190 | 2.6/1.8 | 52 | 30/25 | |
SHMTP19060 | 190 | 2.6/1.8 | 60 | 30/25 | |
SHMTP20060 | 200 | 2.6/1.8 | 60 | 30/25 | |
SHMTP20064 | 200 | 2.6/1.8 | 64 | 30/25 | |
SHMTP21664 | 216 | 2.6/1.8 | 64 | 30 | |
SHMTP23060 | 230 | 2.6/1.8 | 60 | 30 | |
SHMTP23080 | 230 | 3.0/2.0 | 80 | 30 | |
SHMTP25080 | 250 | 3.2/2.2 | 80 | 30 | |
SHMTP25010 | 250 | 3.2/2.2 | 100 | 30 | |
SHMTP30096 | 300 | 3.2/2.2 | 96 | 30 | |
SHMTP30010 | 300 | 3.2/2.2 | 100 | 30 | |
SHMTP35010 | 350 | 3.5/2.6 | 108 | 30 | |
SHMTP35012 | 350 | 3.5/2.6 | 120 | 30 | |
SHMTP40012 | 400 | 3.8/2.8 | 120 | 30 | |
SHMTP45012 | 450 | 3.0/2.0 | 120 | 30 |
