Memo:
Scoring sawblade to be used together with panel sizing blade to avoid chipping on
lower side of panels coated on both sides. Scoring depth up to 2mm. Use on
machines that do not allow adjustment of scoring depth.
| Items No | D(mm) | B/b(mm) | Z | d(mm) | Price (usd) |
| SCOR800808 | 80 | 2.8-3.6 | 8+8 | 20 | |
| SCOR800101 | 80 | 2.8-3.6 | 10+10 | 20 | |
| SCOR100120 | 100 | 2.8-3.6 | 10+10 | 20 | |
| SCOR100122 | 100 | 2.8-3.6 | 10+10 | 22 | |
| SCOR101220 | 100 | 2.8-3.6 | 12+12 | 20 | |
| SCOR101222 | 100 | 2.8-3.6 | 12+12 | 22 | |
| SCOR121220 | 120 | 2.8-3.6 | 12+12 | 20 | |
| SCOR121222 | 120 | 2.8-3.6 | 12+12 | 22 | |
| SCOR125120 | 125 | 2.8-3.6 | 12+12 | 20 | |
| SCOR125122 | 125 | 2.8-3.6 | 12+12 | 22 | |
| SCOR120142 | 120 | 2.8-3.6 | 14+14 | 20 | |
| SCOR120143 | 120 | 2.8-3.6 | 14+14 | 22 |
